1 Fetch the game state

Use fetch to GET your game URL. You'll need async/await to wait for the response. It contains a map array — each entry is one hex on the grid:

// GET /sdb/my-namespace/my-game
{
  "phase": "playing",
  "map": [
    {"type": "land", "unit": null, ...},
    {"type": "land", "unit": "peasant", ...},
    {"type": "impassable", "unit": null, ...},
    // ... 300 hexes total
  ],
  // ...more keys (see API Reference below)
}

Here's what a single hex looks like:

{
  "type": "land",                        // "land" or "impassable"
  "col": 1,                              // grid column (for actions)
  "row": 0,                              // grid row (for actions)
  "x": 45,                               // pixel position from left
  "y": 26,                               // pixel position from top
  "width": 60,                           // hex width in pixels
  "height": 52,                          // hex height in pixels
  "owner": "alice",                      // player name, or null
  "image": "/sdb_apps/antiyoy/images/hex_red.svg",       // hex background image
  "unit": "peasant",                     // unit type, or null
  "unit_image": "/sdb_apps/antiyoy/images/unit_peasant.svg",  // unit overlay, or null
  "building": null,                      // building type, or null
  "building_image": null                 // building overlay, or null
}

2 Loop through the map and show tiles

Use a for-of loop over state.map. For each hex (skip ones where type is "impassable"), create an element, set its src to hex.image (like an img tag), and append it to your container.

Positioning: each hex already has x and y pixel values. Use CSS absolute positioning to place each hex at the right spot. The container needs position: relative, and each hex element gets position: absolute with left = hex.x and top = hex.y.

3 Add overlays (units and buildings)

Each hex can have a unit_image and/or a building_image. These are null when empty, or a URL like /sdb_apps/antiyoy/images/unit_peasant.svg.

Use an if statement to check if the value is not null. If it isn't, add another <img> on top of the hex background, positioned inside the same hex container.

4 Keep it updated

To see other players' moves, use setInterval to fetch the game state every 1-2 seconds and re-render the map.

GET Game State

Fetch the current game state. Use this to render the map, show the lobby, display player info, and check whose turn it is. Poll every 1-2 seconds to keep the UI updated.

// GET /sdb/my-namespace/my-game
{
  "phase": "playing",
  "turn": 5,
  "current_player": "alice",
  "turn_deadline": "2026-03-14T10:00:15Z",
  "players": [
    {"username": "alice", "money": 23, "income": 8, "upkeep": 4}
  ],
  "map": [
    {"col": 0, "row": 0, "x": 0,  "y": 0,  "width": 60, "height": 52, "type": "land", "owner": null,
     "unit": null, "building": null,
     "image": "/sdb_apps/antiyoy/images/hex_neutral.svg", "unit_image": null, "building_image": null},
    {"col": 1, "row": 0, "x": 45, "y": 26, "width": 60, "height": 52, "type": "land", "owner": "alice",
     "unit": "peasant", "building": null,
     "image": "/sdb_apps/antiyoy/images/hex_red.svg", "unit_image": "/sdb_apps/antiyoy/images/unit_peasant.svg", "building_image": null},
    {"col": 2, "row": 0, "x": 90, "y": 0,  "width": 60, "height": 52, "type": "land", "owner": "alice",
     "unit": null, "building": "farm",
     "image": "/sdb_apps/antiyoy/images/hex_red.svg", "unit_image": null, "building_image": "/sdb_apps/antiyoy/images/building_farm.svg"}
  ],
  "winner": null,
  "last_winner": "alice"
}

POST Join

Join the lobby before the game starts. Save the player_key from the response — you need it for every other action.

// Request
{
  "action": "join",
  "username": "alice"
}

// Response (save the player_key!)
{
  "ok": true,
  "player_key": "a1b2c3d4e5f6..."
}

POST Start

Start the game once enough players have joined (1-6). The minimum player count is configurable in database settings (default 1). Anyone in the lobby can send this. The phase switches from lobby to playing, the map is generated with starting territories, and the first player's turn begins.

// Request
{
  "action": "start"
}

// Response
{ "ok": true }

POST Move

Move a unit from one hex to another during your turn. Units can move up to 4 hexes through your own territory and 1 hex into enemy or neutral land. Use col / row from the map data.

// Request
{
  "action": "move",
  "player_key": "a1b2c3...",
  "from": { "col": 3, "row": 5 },
  "to": { "col": 4, "row": 5 }
}

// Response
{ "ok": true }

POST Buy

Buy a unit or building and place it on one of your hexes during your turn. Units can only be placed on empty hexes. Check the Game Rules section for costs and types.

// Request
// type: peasant, spearman, knight, baron, farm, tower, fortress
{
  "action": "buy",
  "player_key": "a1b2c3...",
  "type": "peasant",
  "hex": { "col": 3, "row": 5 }
}

// Response
{ "ok": true }

POST End Turn

End your turn when you're done moving and buying. The turn passes to the next player. If a turn timer is configured, inactivity will auto-forfeit your turn. The timer is configurable in database settings (disabled by default).

// Request
{
  "action": "end_turn",
  "player_key": "a1b2c3..."
}

// Response
{ "ok": true }

POST Surrender

Give up and leave the game. All your territory becomes neutral and your units and buildings are removed. If it was your turn, it passes to the next player.

// Request
{
  "action": "surrender",
  "player_key": "a1b2c3..."
}

// Response
{ "ok": true }

Error Responses

When something goes wrong, the server returns HTTP 400 with a JSON body explaining what happened. For example, trying to buy a unit you can't afford:

// Request
{
  "action": "buy",
  "player_key": "a1b2c3...",
  "type": "knight",
  "hex": { "col": 3, "row": 5 }
}

// Response (HTTP 400)
{
  "error": "cannot_afford"
}

Possible errors:

Game Phases

• Lobby — players join (1-6, minimum is configurable), anyone can start the game
• Playing — sequential turns in join order
• When a player wins, the winner is stored in last_winner and the game returns to lobby

Turn Flow

1. Collect income: +1 per owned hex (0 if hex has tree), +4 per farm
2. Pay upkeep: peasant=2, spearman=6, knight=18, baron=36
3. If money goes negative: all your units die, money resets to 0
4. Take actions: move units, buy units/buildings, then end your turn
5. If a turn timer is set, inactivity auto-forfeits your turn (configurable, disabled by default)

Units

Units move up to 4 hexes through own territory and 1 hex into neutral/enemy territory. Each unit moves once per turn. Moving onto a friendly hex with a lower-level unit merges them (peasant + peasant = spearman, etc.).

Buildings

Buildings are placed on any owned hex without a unit or building. They are destroyed when the hex is captured. Buildings cannot move.

Economy

• Each owned hex gives +1 income
• Each farm gives +4 income
• Hexes with trees give 0 income (not +1)
• Unit upkeep is paid each turn
• Net income = hex income + farm income - unit upkeep

Protection

Units, towers, and fortresses protect adjacent hexes. An attacker must have a higher level than the highest adjacent protector. Protection does not stack.

Trees

Trees start on neutral hexes and spread every 2-6 turns to adjacent neutral land. A hex with a tree produces 0 income. Send a peasant to chop it (move onto the tree hex).

Connectivity

At the end of each turn, your territory is checked for connectivity. If your territory splits into disconnected chunks, only the largest chunk survives — smaller chunks become neutral and all units/buildings on them are destroyed.

Win Conditions

• Domination — own 70% or more of habitable hexes
• Elimination — a player who loses all their land is eliminated
• Last standing — if only one non-eliminated player remains, they win

My actions don't work

When an action fails, the server always responds with an error message in the JSON body. Use console.log() or alert() to display the response from the server and figure out the problem. See the Error Responses table above for all possible errors.

My actions don't work after refresh

When you refresh the page, you lose the player_key that was stored in your JavaScript variable. Without it, the server doesn't know who you are. Save your player_key to localStorage right after joining, and load it back when the page loads. That way a refresh won't break your game.

Clicking on a unit doesn't select the hex tile

Your click event is set up on the hex tile, but the unit is a separate image sitting on top of it. When you click, the browser fires the event on the unit image instead of the hex behind it. Use pointer-events: none on your overlay images (units and buildings) so that clicks pass through to the hex tile underneath.

How to highlight a hex so it looks good

Use the CSS filter property with brightness(). For example, filter: brightness(1.3) makes a hex 30% brighter — great for hover effects or showing a selected tile.

How do I know which hex was clicked?

Two approaches:

1. Use dataset — when creating each hex element, store the col and row from the data on the element (e.g. el.dataset.col = hex.col). Then read them back in your click handler.
2. Use addEventListener — attach the click handler to each hex right when you create it in the loop. The hex variable is captured in the callback, so you already have access to hex.col and hex.row.

My game is stuck in 'playing' mode so I can't join

Go to the SDB Dashboard, open your database settings, and reset the game. This puts it back into lobby mode.
